Tough Operating Environments Require Cables Engineered for Longer Service Life and Increased Productivity
AmerCable has an automotive cable productivity solution for you. Our innovatively engineered and manufactured Automotive Cable family is designed for your toughest conditions. As a leading producer of automotive cables in North America, AmerCable is dedicated to producing
- Highly flexible and reliable cables
- Cables that last longer in harsh automotive manufacturing environments
- Cables designed to help provide greater levels of safety and productivity
WPCS: Weld Primary Cable
Round
WPCS 2000 Volts (UL) • 1000 Volts c(UL)
- Primary power connections to transformers (2/C plus ground)
- Main power drop to a three-phase weld controller from a bus plug (3/C plus ground)
Features
- Suitable for continuous operating conductor temperature of 90°C
- Extremely flexible stranding used for increased flexibility and ease of installation
- Insulated with EPR meeting the requirements of ICEA S-68-516
- Serrated insulation and special length of lay to insure long flex life
- Heavy duty jacket offers excellent protection against abrasion, impact, heat, oil, flame, ozone, alkali and acids
- Jacket extruded into cable core interstices to ensure durability
- Suitable for extra hard usage n Rated by GM as Class 3 cable, suitable for continuous duty flexing service at moderate speeds with extensive high count flex life and moderate amounts of torsional stress
WPCS: Weld Primary Cable
Flat
WPCS 600 Volts (UL) • 1000 Volts c(UL)
- Main power drop from bus plug to single-phase weld controller
- Power drop from weld controller to conventional AC transformer
- Power drop from weld controller to junction box for automatics
Features
- Suitable for continuous operating conductor temperature of 90°C
- Extremely flexible stranding used for increased flexibility and ease of installation
- Phase conductors insulated with EPR meeting the requirements of ICEA S-68-516
- Heavy Duty jacket offers excellent protection against abrasion, impact, heat, oil, flame, ozone, alkali and acids
- Innovative design reduces diameter and weight
- Rated by GM as Class 2 cable, suitable for periodic flexing
- Suitable for extra hard usage
